PV-LCB-8M
PV-LCB-8M is a part of our LCBR45 battery rack series which is one of our many options for energy battery solutions that provides these characteristics – it’s ease of installation and maintenance, and its LFP high-capacity Li-Ion battery with aluminum shell (Over 130wh/kg), it has a long lifespan.
FEATURES
Indoor Batter Rack
IP20 Rating
Local & Remote Management
Self-developed 3-levels BMS
Complex Protection
Safe & Reliable
Standard & Module Design
Seamless On/Off grid transfer
Color options: Greyish White
APPLICATION AREAS
Specialized Use (Indoor): Battery rack that is intended for personal/commercial use.
SPECIFICATIONS
PV-LCB-8M - 28"
Code
PV-LCB-8M
Dimensions
705*645*197 mm
Max Input Voltage
1000V
Max String Isc
10A
Number of Input String
8
Input Cable Gland
4 mm - 8 mm cable diameter
Number of Output
1
Max Output Current
160A
Output Breaker
200A
Output Cable Gland
13 mm - 18 mm cable diameter
